Types of Stainless Steel Gratings
- Top Notch Grating: Designed for durability and precision in demanding environments.
- Pass-Thru Grating: Ideal for applications requiring smooth transitions and ease of installation.
- Press Lock Grating: Engineered for strength and versatility in multiple applications.
Top Notch Grating
Top Notch Gratings is constructed by Rectangular Flats and Round Bars. The grating will have the round bar on the top of the grating by using manual punching method.
Specification
| Load Bar Height |
20,25,30,40,50 upto 60mm |
| Load Bar Thickness |
3,4,5 & 6mm |
| Cross Bar |
6,8 & 10mm Round (or) 6,8 & 10mm Square Bar |
| Load Bar Type |
Plain (or) Serrated |
| Material |
Stainless Steel AISI 304/ 304 L/ 316/ 316 L Grade |
| Finish |
Mill Finish/ Brush Finish/ Mirror Finish/ Electro Polish Finish |
Application: Platform Walkways in Oil and Gas Sector, Petrochemical Industries, Civil Construction, Food Industries etc.,
Pass Thru Gratings
Our Pass Thru This Grating is constructed by Rectangular Flats and Round Bars. The Grating will have the round bar on the Centre of the Flat bar by using manual punching method.
Specification
| Load Bar Height |
20,25,30,40,50 upto 60mm |
| Load Bar Thickness |
3,4,5 & 6mm |
| Cross Bar |
6,8 & 10mm Round Bar |
| Load Bar Type |
Plain (or) Serrated |
| Material |
Stainless Steel AISI 304/ 304 L/ 316/ 316 L Grade |
| Finish |
Mill Finish/ Brush Finish/ Mirror Finish/ Electro Polish Finish |
Application: Platform Walkways in Oil and Gas Sector, Petrochemical Industries, Civil Construction, Food Industries etc.,
Press Lock Gratings
This type of Gratings will be constructed with the Rectangular Flats. In this type grating, both the flats will be intersected to each other and perpendicular to each other.
Specification
| Load Bar Height |
20,25,30,40,50 upto 60mm |
| Load Bar Thickness |
3,4,5 & 6mm |
| Cross Bar Height |
10,12,15,20,25,30,40,50 upto 60mm |
| Cross Bar Thickness |
3,4,5 & 6mm |
| Load Bar Type |
Plain (or) Serrated |
| Material |
Stainless Steel AISI 304/ 304 L/ 316/ 316 L Grade |
| Finish |
Mill Finish/ Brush Finish/ Mirror Finish/ Electro Polish Finish |
Application: Vehicle Passing Trench, Platform Walkways in Oil and Gas Sector, Petrochemical Industries Civil Construction, Food Industries, Kitchens, etc.,
Crossroads Services Co. LLC ensures that all stainless steel gratings are crafted to meet stringent requirements for corrosion resistance, durability, and performance. Contact us to discuss your project needs and find the perfect solution.
